| NAME AND TYPE |
MAIN TECHNICAL DATA |
Q'TY |
| ZS5 Raw Material Conveyor |
Power:3kw,It is used to transport the raw material to the Hydrapulper |
1 set |
| ZSG-5 Hydrapulper |
Effective Volumme: 5m3，Power:75kW, Material of Tank and Blade : Carbonized Steel |
1set |
| PZ-5 Operation Platform |
For Hydrapulper |
1 unit |
| ZZF31 Separator |
Power:37kw |
1set |
| Vibrating screen |
0.9m2,dealing with impurities,3.0kW |
1set |
| JB-160-210Agitator |
Reducer(3kw ）,splatter and shaft are made of stainless steel |
3sets |
| MOR200 Consistency Controller |
Range：0.6%-6.0% |
1set |
| TJ100 Pulp Proportioning Tank |
Stainless Steel |
1set |
| Automatic Control Appliance |
Used to control the Pneumatic parts in the pulping system including sensor,pneumatic valve,pneumatic control cabinet,solinoid reversing valve,Air source triad,controlling Pipes |
1set |
| KZT100 Pulping Control System |
control the pulping system automatically,including2cabinets |
1set |
| KZT100 Pulp Proportioning Control System |
control the pulping proportioning system automatically |
1set |
| XZ6.6—16546 Rotary Forming Machine |
Double rotary model, each rotar has 6 faces,4pcs output per cycle,power:18.5kW |
1 set |
| PX-100 Operation Platform |
Matched with forming machine |
1unit |
| GZ-10000 Auto Draigning System |
Matching with Forming System,include Air-water Seperation Tank,Auto Drain Tank,Support,Check Valve,Electromagnetic Valve,Inductor etc |
1set |
| KXZ100 Main Machine Control System |
use PLC,touch screen control automatically forming machine,drying machine vacuum system、water treatmentand auxilairy systems. |
1set |
| HR10-16535-25E Drying Line |
Effective width 1650mm,transfered speed adjustable.The length of drying section : 30000mm. Fuel : Diesel oil/Nature gas/LPG.power:about 105kw |
1set |
| PH-10 Operation Platform |
Used for burner operation |
1unit |
| WT -10 Movable Ladder |
for inspection and mainteance of drying line |
1unit |
| SC-165 Finished Product Conveyor |
power: 2.2kw |
1 unit |
| DB4 Stacker |
Drived by compressed air |
1 set |
| YJ-140 Height Limit Pressor |
Used to limit the height of the products after stacking |
3 sets |
| TD-L15 Cooling Tower |
used to cool the vacuum sealing water |
1 set |
| Sidehill Screen |
used for further screening of white water |
1 set |
| TA White Water Sedimentation tower |
3000*3000*7000mm,made of carbonized steel,lined by glass fibre reinforced plastic |
1 set |
| Steel Parts of White Water Secondary Sedimentation Tank |
steel works,setting tube and frame |
1 set |
